Z-axis motorised stage VHX-S700F

VHX-S700F - Z-axis motorised stage

*Please note that accessories depicted in the image are for illustrative purposes only and may not be included with the product.

Data Sheet (PDF)

  • CE Marking
  • CSA

Specifications

Model

VHX-S700F

Z stage

Z motorized/manual stage

Motorized

Z motorized stage motor

5-phase stepping motor

Z motorized stage resolution

0.1 µm (typ.)

Z motorized stage movement speed

17 mm/sec (max)

Z stage movement amount

49 mm

Ratings

Power voltage

12V DC 2.5 A

Power consumption

30 VA

Environmental resistance

Ambient temperature

+5 to 40 °C

Relative humidity

20 to 80% RH (no condensation)

Weight

Approx. 3.5 kg
